半鋼子午胎胎坯內外噴涂生產線
設備用途 Equipment use
用于半鋼子午胎胎坯的隔離劑內外噴涂
It is used in the inner and outer dusting agent coating of semi-steel radial tire green tyre (spray Line)
設備特點Equipment characteristics
進入輥道輸送機、胎坯定中裝置、升降裝置、機械手旋轉裝置、內外噴涂系統、機械手清潔裝置、烘干裝置、輸出輥道輸送機、旋轉除塵裝置等組成。
It consists of roller entrance & conveying machine, green tyre centering unit, hoisting unit, mechanical hand rotating unit, inner and outer coating system, manipulator cleaning unit, mechanical hand cleanting unit, drying unit, output roll conveyor machine and rotary dedusting unit etc.
外噴2-4秒 Outer spraying is 2-4s.
|
主要技術參數Main technical parameters |
|
序號 № |
胎坯噴涂方式
Green tyre spray painting method |
胎坯適用規格Applicable green tyre specification |
坯胎適用外徑Applicable green tyre outer diameter |
|
1 |
內噴/外噴Inner spray painting/ outer spray painting |
12〞-22〞 |
Ф450mm-Ф1000mm |
|
2 |
坯胎適用高度
Applicable green tyre height |
坯胎最大重量
Maximum green tyre weight |
胎坯內噴涂時間
Coating time of inner spray painting |
|
3 |
200mm-450mm |
Max.45kg |
內噴2-3秒Inner spray painting 2-3s |
|
4 |
胎坯外噴涂時間Green tyre outer spray painting time |
機械手旋轉工位
Manipulator rotating station |
胎坯噴涂日產量
Daily output capacity of green tyre spray painting |
|
5 |
外噴2-4秒Outer spray painting 2-4s |
5-6工位 5-6 stations |
6000-7000條/日6000-7000 pcs/day |
